EOS 46.U
Behind-the-bench sauna heater
EOS Euro
Description
Description
Premium sauna heater for private and commercial sauna operation.
Versatile wall-mounting or floor-standing model (feet optionally available), for the dry Finnish sauna.
Robust and durable, thanks to the triple-shell construction.
Rock store as additional inner shell made of stainless steel. Outer shell made of stainless steel. Die-cast iron top. Terminal box at the rear. Wall-mounting brackets included. 12 kW version completely made of stainless steel.
Rock store fits up to 15 kg stones.
Your Advantages
- Premium sauna heater for sauna cabins from 7 to 18 m³.
- Wall-mounting or floor-standing model (with optional feet).
- Space-saving design - only 35 cm depth.
- Durable triple-shell construction, made of stainless steel.
- Optimal relation between stone volume and air convection system for fast heat-up times and powerful water splashes.
- Rock store fits up to 15 kg stones.
Model Overview
| Power | Item no. |
|---|---|
| 7,5 kW | 907686 |
| 9,0 kW | 907687 |
| 10,0 kW | 947886 |
| 10,5 kW | 945185 |
| 12,0 kW | 908076 |
Technical Specifications
Electrical connection | 400 V 3N ~ 50/60 Hz |
Fuse protection (control unit) | 3 x 16 A |
Fuse protection (LSG) | no / 3 x 16 A (only 12,0 kW) |
Dimensions H/W/D, in cm | 61 (74*) / 46 / 35 (* Height of device incl. feet) |
For sauna cabin size (7,5 / 9,0 / 10,5 / 12,0 kW) | 7 - 10 m³ / 9 - 14 m³ / 11 - 16 m³ / 14 - 18 m³ |
Min. size air inlet and outlet (7,5 / 9,0 / 10,5 / 12,0 kW) | 35 x 5 cm / 35 x 5 cm / 35 x 7 cm / 35 x 7 cm |
Weight withouth rocks (7,5 / 9,0 / 10,5 / 12,0 kW) | 18,0 kg / 18,0 kg / 19,5 kg / 19,5 kg |
Stone filling | 15,0 kg |
Power extension required | no / PEB 10 (only 12,0 kW) |
