EOS EmoTec H

Premium-class digital sauna control unit for dry & humid sauna operation.

All functions like EOS EmoTec D, but additionally with humidity control. With compact control panel with colour display and a separate relay box. Thanks to the innovative navigation concept, EOS EmoTec Control H allows easy and intuitive operation, all major functions can be reached and set within a few seconds.

For all EOS Bi-O type sauna heaters.

Humidity control - either in proportional to time way (allows constant steam production per given time) or with an optional humidity sensor as per relative air humidity (allows exact humidity setting per rel. air humidity in %).

Output for vaporizer up to 3 kW. With water shortage detection. Quick selection between dry sauna or humid sauna operation modes with a jog-dial.

With the additional convenient features:

• After-heating (sauna dry program after humid mode)
• Adjustable after-heating temperature
• Adjustable after-heating extractor fan speed
• Adjustable after-heating time
• Adjustable grace time for refilling the water tank by low level
• Smart-Heat functions heats up the sauna faster and prevents that the steam production starts while the sauna is not yet well heated

• For dry and humid sauna operation. Temperature control:
  • 30 °C - 115 °C (in dry Finnish sauna mode)
  • 30 °C - 70 °C (in humid sauna operation).
• For all EOS Bi-O type sauna heaters:
  • Humidity control - proportional to time (10 steps) or as per relative air humidity in % with an optional humidity sensor.
  • Numerous comfort functions such as sauna-dry mode, adjustable after-heating temperature, fan runtime, after-heating time, smart-heat function in humid mode and much more.
  • Guided setup, pin-code protected service level, additional innovative smart features (software updates, custom firmware, etc.).
• Compact-size control panel with a TFT colour display with flush-mounted or surface-mounted installation.
• Display panel available in anthracite, black or white design.
• Menu navigation in 19 languages (DE, EN, FR, RU, ES, NL, IT, PL, SLO, FIN, TR, CZ, RO, BG, HU, HR, SK, DK).
• Innovative operation with jog-dial switch - simple, easy, intuitive.
• With a separate slim-size display panel (can be installed up to 100 m away from the sauna).
• Dimmable cabin light output 230V, automatic detection of inductive and capacitive loads.
• Output for ventilation fan 230V (3 speeds).
• 24 h pre-set timer and extended week timer (4 programs per day possible).
• Heating time limitation 6 h / 12 h / unlimited.
• Display panel with screen saver and sleep mode.
• Holiday home mode and display lock per pin code.
• Pin code protected service level for setup and fine-tuning.
• Volt-free output.
• Digital type sensor for precise and interference-resistant control. Bench sensor optionally available.
• Quick check for pre-set and real temperature in the sauna.
• Digital microchip based temperature sensor with 5 m cable.
• Firmware can be updated with a micro SD card (not included).
• Additional control features through optional extensions: coloured light control for LED, music control, remote start and operation.
• Switching capacity 9 kW, extendable.
• Power supply 400V 3N AC.
